Steel Tube Laser Cutting Machines

Steel Tube Laser Cutting Machines

1.Professional metal pipe tube cutting machine. 2.High cutting precision and speed. 3.All kinds of tube shapes. 4.Strong machine body never deformation. 5.Patent automatic loading system, only about 15s loading time. 6.500W-4000W wide range power source. 7.Max 30mm cutting thickness.

Product Details



I. KEY FEATURES

●  Germany PA8000 Control System

●  Spain Lantek Nesting file

●  Yaskawa Servo Motor

●  IPG or Raycus resonator

●  Strong and reliable machine bed


II. PARAMETERS

No.

Item

Parameter

1.

Maximum Travelling speed

70m/min

2.

Laser wavelength

1070-1080 nm

3.

Minimum cutting width

0.2mm

4.

Rated output power

10--100% (100W-1000W)

5.

X And Y axis positioning accuracy

≤±0.03㎜

6.

Repeat positioning accuracy

≤±0.02㎜

7.

Available cut pipe shape

Round tube, square tube,   rectangular tube

Oval tube, fan-shaped tube and so   on


image002.png image003.png image004.png image005.png

8.

Acceleration

1G

9.

Oiling systems

Automatic oiling

10.

Tail(Waste) length

200-250mm

11.

Effective length of cutting

6000mm/8000mm/10000mm(customize   dorder acceptable)

12.

Size

11*3.9*2.5m (Length * width *   height)

13.

Power

35KW

14.

G.W.

10 Ton

15.

Power supply

380v50Hz ±10%

16.

Red Positioning

Yes

17.

Auxiliary gases

Oxygen, nitrogen, air

18.

Supported file formats

IGS (Available PRO/E. UG, Solid works Photo)

19.

Diameter

20mm-200mm (customized   order acceptable)

20.

Laser tracking system

Automatic follow-up


III. MACHINE DETAILS

IV. SAMPLES


V. FACTORY REVIEW

20000 SQUARE METER FACTORY

ADVANCED HIGH PRECISION MILLING CENTER FOR ESSENTIAL PARTS
