LT-6025EKA Bevel Pipe Cutting

Technical Specification

Pipe Cutting Range

Length and Diameter

6200mm×φ20-350mm

6200mm×□20-350mm

12100mm×φ20-350mm

12100mm×□20-350mm

X Travel

400mm

3KW

Y Travel

7350mm

5KW

A、B Travel

Unlimited Rotation

A Axis 7.5KW B Axis 5KW

Z Travel

250mm

1.5KW

Bevel Angel

±45°

X、Y Positioning Accuracy

±0.03mm/1000mm（±0.05mm/Full pipe length）

X、Y Repeat Positioning Accuracy

±0.05mm

X or Y single Axis Max. Speed

120m/min

A Max. Positioning Speed

120rpm

The cutting speed and travel speed will be lower according to the increase weight of pipe.

Pipe Loading Length

≤6200mm(6m loading)

≤12100（12m loading）

Semi-automatic

Maximum Weight Bearable for Loading

1400kg(6m loading)

4500kg(12m loading)

G.W.

7500Kg(6m)

12000Kg(12m)

Machine Dimension

12750×4550×2250mm（L×W×H）

Power Supply Requirement

3/380V/50Hz

Total Power

55KW

60KW 12m

Power Protetion Level

IP54

No.

Item

No.

Brand

1

Laser Source

1

IPG3000w

2

Laser Head

1

Germany LT

3

Cutting Software

1

TubePro

4

Front Chuck

1

Full Stroke Pneumatic Chuck

5

Back Chuck

1

Full Stroke Pneumatic Chuck

6

Machine Bed

1

Acme Laser

7

Contactor and Air Switch

1

Schneider

8

Pneumatic Switch

1

AirTAC

9

Rail

1

HIWIN

10

Rack and Pinion

1

YYC

11

Other parts on machine bed

1

Acme Laser

12

Machine Motor and Driver

1

Japan Panasonic（EtherCAT）

13

Reducer

1

Japan Shimpo

14

Pipe Support

1

Servo Floating Support

15

Proportional Valve

1

Japan SMC

16

Water Chiller

1

Tongfei or Hanli

17

Nesting

1

TubesT

18

Control System

1

FSCUT5000A

19

Loading System

1

Semi-automatic Loading

20

Pipe Parts Support

1

Servo Floating Panel
