Machine Main Parts
|
Maxphotonics Fiber laser source
l 2 years warranty time. l More than 100,000 hours life time. l Low Energy Consumption l Save energy and protect environment. l Photoelectric conversion rate is up to 30% |
| RayTools BM111 Auto-focusing laser cutting head
l With Anti-crash function, good sealed, high pressure resistant, auto-tracking system and anti-crash and stop system. l Perforation speed is one to two times faster than manual focusing. Perforating speed can shorten the cutting time. |
| Auto Height Controller BCS100E capacitive height controller provides excellent performance in distance control. It served as height follow unit for FSCUT laser cutting control system via Ethernet communication, can realize functions including height sensing, segmented and stepping pierce process, detect and find workpiece edge, vibration suppression etc. Latest anti-collision function can effectively avoid tip-up collision risk in production. |
|
CYPCUT FSCUT 5000A EtherCAT CNC Cutting Control System
FSCUT5000 series is EtherCat bus system specially designed for tube cutting application.From among, FSCUT5000 applied for 3-chuck structure machine, work with TubesT 3D nesting software, it will achieve most efficiency and slightest waste. |
|
TubesT 3D Tube Nesting Software
TubesT is a 3D tube nesting software designed for CypTube/TubePro laser cutting system. From parts drawing and modification, full type compensation, strategic nesting to report generation, using TubesT will meet and exceed your production needs. |
|
Machine body processing by big CNC Milling Center
l Every mounting slot and screw hole for installation of rails and racks is milling out by this big milling center. l High Accuracy and Smooth Movement |
| Patent Technology 8 cylinders Pneumatic Chuck l Square hole design, stronger passing ability; l The clamping force can be adjusted. intelligently, suitable for different types of pipe processing requirements; l The clamping range of full stroke, without manual adjustment; l With an eight-cylinder structure, the clamping force is twice that of ordinary chucks; l Precision grinding gear drive, stronger power and higher efficiency; l The highest level of dustproof, stronger stability |
| It can effectively clamp various shapes of profiles, such as: square tube, round tube, rectangular tube, oval tube, flat oval tube, channel steel, H steel, angle iron, triangle tube, etc. |
|
3 Pneumatic Chucks Both Can Move Cutting head can go behind middle chuck，do cutting between middle chuck and rear chuck，achieve 0 tube tailing，no tube waste. |
|
Front chuck and Middle chuck |
|
Middle chuck and Rear chuck
|
|
All 3 Chucks is 8 cylinders Pneumatic 170mm chuck auto-centering |
|
Servo Floating Tube Supporter l Can following tube up and down during tube rotation always provide a good support, guarantee a high cutting accuracy l Especially suitable for Square, Rectangle, Angle, Channel, I , H beams |
