1500W Combined Fiber Laser Cutting Machine

• China FSCUT3000S Cutting Control System
• Special steel centering. Support L steel, channel steel, I-beam and other special steel centering to improve the cutting accuracy.
• Pipe surface profile correction. For workpieces with stable deviations on the pipe surface, it can effectively compensate for regular cutting deviations, reduce the accuracy requirements for raw materials, and reduce waste.
• Single-sided centering. It can effectively solve the problem of the accuracy of the pipe hole position and improve the accuracy of the edge-to-edge distance of the hole position.
• One-key alignment of the tube head. Using the cutting head to align the tube head can effectively reduce the time of manual alignment and reduce the front-end waste of manual alignment.

MAX Laser Source

• Excellent Material Processing Performance. High speed in thin sheet cutting & Strong capability in thick material processing.
• Compact Design, Maintenance Free. Highly integrated system with modular design & Easy maintenance significantly reduce TCO.
• Smaller Size with Higher Stability. >60% reduction in volume & Higher flexibility when integrated into system.
• High Level Vertical Integration. All key components are designed and produced in house & Strict quality control, high consistency and reliability.

OSPRI LC40 Auto-Focus Laser Head

• High speed servo collimation zoom.
• The three protective lenses are tightly sealed against dust.
• The independent module of the focus protection window is easy to replace.

Front Pneumatic Chuck

• Square hole design, stronger passing capacity.
• The clamping force can be adjusted intelligently, which is suitable for different types of pipe processing requirements.
• Full-stroke clamping range, no need for manual adjustment.
• Eight-cylinder structure is adopted, and the clamping force is twice that of ordinary chucks.
• Precision grinding gear transmission, stronger power and higher efficiency.
• High dustproof level, stronger stability.

Rear Pneumatic Chuck

The lengthened design of the rear chuck can go deep through the front chuck to achieve "zero tailing" cutting in the case of two chucks.

Adjustable Wheel Tube Support

Equipped with a lifting support mechanism with multiple rotatable wheels. The lifting mechanism can realize pneumatic control and automatic lifting. When the processed pipe changes, the support wheel can be adjusted to make the support wheel the same diameter as the processed pipe.

Item

LP-3015DT17

Tube Length

≤6000mm

Machine Power

10.6kw

≤300kg

Cutting Size

3000mm×1500mm

Tube Diameter

≤165mm

Y Axis Travelling

3080mm

Space

9500mm×3220mm×1800mm

2320mm

Power

1KW-6KW

250mm

Machine Weight

6.3Ton

±0.03mm/1000mm

1.5G

X, Y Axis REPEAT POSITIONING ACCURACY

±0.02/1000mm

AC 380V/50HZ

Maximum bearing weight of working table

1200kg

Auxiliary Gas

Oxygen, Air, Nitrogen
